EPOXY PAINTS
NEOGUARD Epoxy Paints are 'Epoxy' based top coat offering good resistance to water and humidity. These products are designed to offer superior corrosion protection to mild steel substrates. The product has got excellent adhesion strength and also offers a balanced aesthetic and corrosion protection. NEOGUARD epoxy Paints also show good Chemical & Salt Resistance. Neo Guard Epoxy Paints are available in High Glossy / Semi Glossy varieties. Special products with accelerated curing speed are also available.
ZINCGUARD,a two components high performance epoxy metallic zinc rich primer, specially formulated for excellent corrosion resistance for high performance system.
GRADES WITH TECHNICAL SPECIFICATIONS
NEOGUARD 5150 - EPOXY PAINT SEMI GLOSSY
Product |
NEOGUARD FR 5160 -
EPOXY FDS PAINT |
Description |
2 Parts air drying, Epoxy spl. polymer cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
ET-501 / ST-400 |
NEOGUARD FR 5160
Product |
NEOGUARD FR 5160 -
EPOXY FDS PAINT |
Description |
2 Parts air drying, Epoxy spl. polymer cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
ET-501 / ST-400 |
NEOGUARD HB 5170 -
EPOXY HB PAINT
Product |
NEOGUARD FR 5160 -
EPOXY FDS PAINT |
Description |
2 Parts air drying, Epoxy spl. polymer cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
ET-501 / ST-400 |
NEOGUARD FD 5180 -
EPOXY PAINT FD
Product |
NEOGUARD FR 5160 -
EPOXY FDS PAINT |
Description |
2 Parts air drying, Epoxy spl. polymer cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
ET-501 / ST-400 |
NEOGUARD 5200 -EPOXY LACQUER
Product |
NEOGUARD 5200 -
EPOXY LACQUER |
Description |
2 Parts air drying clear, non yellowing epoxy clear coating |
Solids |
48 |
DFT (microns) |
25-30 |
Coverage (Sq. Mt. / litre) |
16-19 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-80-90 Mins.
Tack free- 6-7 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
ET-501 |
NEOGUARD 5251 -EPOXY PAINT High GLOSS
Product |
NEOGUARD 5251 -
EPOXY PAINT High GLOSS |
Description |
2 Parts air drying, Epoxy spl. polymer cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
- |
NEOGUARD FD 5203 -EPOXY PAINT FD GLOSSY
Product |
NEOGUARD FD 5203 -
EPOXY PAINT FD GLOSSY |
Description |
2 Parts air drying, special polymer based cured finish paint. |
Solids |
40 |
DFT (microns) |
30-35 |
Coverage (Sq. Mt. / litre) |
11.4-13.3 |
Pot Life |
4 hrs |
Over Coating Interval (Min) |
24 hrs |
Over Coating Interval (Max) |
7 Days |
Drying time @ 30oC |
surface dry-40-50 Mins.
Tack free- 4-5 Hrs.
Hard dry- 24 Hrs. |
Use Thinner |
- |
COAL TAR EPOXY
Product |
COAL TAR EPOXY |
Description |
Seamless coating with better protection, For interior and exterior use with High strength & better flexibility. |
Solids |
87 |
DFT (microns) |
100 – 150 µm |
Coverage (Sq. Mt. / litre) |
7 sq.mtr/ltr @ 100 µm THICK |
Pot Life |
3 hrs |
Over Coating Interval (Min) |
- |
Over Coating Interval (Max) |
- |
Drying time @ 30oC |
surface dry - 4 – 5 Hrs.
Hard dry- 24 hrs. |
Use Thinner |
ET-509 |
ZINCGUARD 900
Product |
ZINCGUARD 900 |
Description |
A two components high performance epoxy metallic zinc rich primer, specially formulated for excellent corrosion resistance for high performance system. |
Solids |
90 +/- 5% |
DFT (microns) |
50-75 µm |
Coverage (Sq. Mt. / litre) |
11 sq.mtr/ltr @ 50 µ DFT |
Pot Life |
2-3 Hrs |
Over Coating Interval (Min) |
- |
Over Coating Interval (Max) |
- |
Drying time @ 30oC |
Tack Free Dry – 10 Min Max
HARD DRY: 5 Hrs
Full cured – 7 days |
Use Thinner |
|
ZINCGUARD 960
Product |
ZINCGUARD 960 |
Description |
A two component solvent based moisture curing inorganic zinc silicate coating, specially formulated for excellent corrosion resistance for high performance system |
Solids |
90 +/- 5% |
DFT (microns) |
50-75 µm |
Coverage (Sq. Mt. / litre) |
11 sq.mtr/ltr @ 50 µ DFT |
Pot Life |
2-3 hrs |
Over Coating Interval (Min) |
- |
Over Coating Interval (Max) |
- |
Drying time @ 30oC |
Tack Free Dry – 10 Min Max
HARD DRY: 5 Hrs
Full cured – 7 days |
Use Thinner |
|
APPLICATIONS
SURFACE PREPARATION:
Abrasive blasting to Sa 2 ½ Swedish standards is the best method of surface preparation. In case blasting is not possible, then the surface of steel should be cleaned to St-2/St-3. The surface should be absolutely dry, moisture and oil free before primer application. And for Application on Primer scuff with 100 no type’s emery paper for proper bonding and performance.
APPLICATION METHOD:
Stir the Base part thoroughly. Mix base and Hardener as per our recommended ratio, by volume, Allow the mixture to stand still (maturation) for about 10-15 minutes to initiate the reaction. Add suggested Thinner into mix, if required, depending on application method, and stir gently for few minutes. Stain the paint through nylon filter cloth of 100 mesh size and apply uniformly over the surface. All equipment used for above should be properly cleaned. Apply By Brush/By Conventional spray.
APPLICATION AREAS:
General purpose coating for steel which resists water, mild chemical & abrasion. It is recommended as Topcoat on epoxy primer/Trucoat on M.S Surface for OEM’s as well as for process industries like fertilizers, refineries, chemical and other plants. It can also be applied in diverse areas of tank exteriors, equipment’s, pipelines, structural steel, etc. Not to be used for immersion application.
